Operating conditions:
Temperature: -40℃-150℃
Pressure: ≤1.7MPa
Speeds: ≤13m/sec
Applications: Used in different pumps, mixers and other rotating equipments which apply to oil, GRUNDFOS Stainless Steel Vertical multistage centrifugal pump.
Materials:
Rotary ring (SiC/ TC)
Stationary ring (Carbon/ SiC/ TC)
Secondary seal (NBR/ VITON)
Spring & Other parts (SUS304/ SUS316)
Materials should be selected according to operation condition
The Stainless Steel Multistage Centrifugal Pumps Mechanical Seal is a precision-engineered sealing solution designed to meet the demanding requirements of a wide range of applications. This innovative mechanical seal is crafted from high-quality materials and is capable of operating under conditions, making it a reliable choice for various pumps, mixers, and rotating equipment, especially those found in oil and GRUNDFOS Stainless Steel Vertical multistage centrifugal pumps.
Operating Conditions:
Temperature: This mechanical seal can function flawlessly within a temperature range of -40℃ to 150℃. Whether you're dealing with cold or high-temperature processes, this seal can maintain its integrity.
Pressure: With a pressure tolerance of 1.7MPa, this mechanical seal can effectively contain and manage pressure variations, ensuring a secure and reliable seal within the demanding applications.
Speeds: The Stainless Steel Multistage Centrifugal Pumps Mechanical Seal is capable of operating at speeds up to 13 meters per second, making it a suitable choice for high-speed rotating equipment.
Applications:
The versatility of the Stainless Steel Multistage Centrifugal Pumps Mechanical Seal extends to its broad range of applications, where its good performance stands out. This mechanical seal finds use in:
Pumps: Whether it's a centrifugal pump, multistage pump, or any other type of pump, this mechanical seal ensures leak-free operation, promoting efficiency and reliability.
Mixers: In the world of mixing equipment, this mechanical seal plays a pivotal role in maintaining a tight seal even under varying speeds and pressures.
Rotating Equipment: Any equipment with rotating components benefits from the reliable sealing provided by this mechanical seal. This includes motors, agitators, and more.
GRUNDFOS Stainless Steel Vertical Multistage Centrifugal Pump: This mechanical seal is a fit for the GRUNDFOS Stainless Steel Vertical Multistage Centrifugal Pump, a renowned and high-performance pump used across various industries.
Materials:
Rotary Ring: Available in options of Silicon Carbide (SiC) or Tungsten Carbide (TC), the rotary ring is designed to withstand harsh conditions and provide reliable sealing.
Stationary Ring: The stationary ring comes in three material options - Carbon, Silicon Carbide (SiC), and Tungsten Carbide (TC). These materials are selected based on the specific application and its requirements.
Secondary Seal: The secondary seal options include Nitrile Butadiene Rubber (NBR) and VITON, offering chemical resistance and flexibility to adapt to diverse situations.
Spring & Other Parts: Springs and other components are constructed from high-grade stainless steel, specifically SUS304 and SUS316, ensuring longevity and resistance to corrosion.
Material Selection:
It is crucial to choose the appropriate materials for each component of the Stainless Steel Multistage Centrifugal Pumps Mechanical Seal based on the unique operational conditions of the application. By selecting the right materials, users can ensure the longevity and reliability of the mechanical seal, preventing premature wear and reducing maintenance costs.
In conclusion, the Stainless Steel Multistage Centrifugal Pumps Mechanical Seal is a high-performance sealing solution that excels in challenging conditions.
