Operating conditions:
Temperature: -40℃-150℃
Pressure: ≤2MPa
Speeds: ≤13m/sec
Applications: Used in different pumps, mixers and other rotating equipments which apply to oil, water and other weak corrosive solutions.
Materials:
Rotary ring (Carbon/ SiC)
Stationary ring (Ceramic/ SiC/ TC)
Secondary seal (NBR/ EPDM/ VITON)
Spring & Other parts (SUS304/ SUS316)
Materials should be selected according to operation condition
Design Features:
1. Single face, single spring, unbalanced, rubber bellows structure.
2. The seal face is driven through the spring seat, rubber bellows design to avoid torsion.
3.The installation size conforms to the standard for ISO3069 and DIN24960.
When it comes to heavy-duty water pumps and other rotating equipment that handle oil, water, and weak corrosive solutions, the Heavy Duty Water Pump Mechanical Shaft Seal stands out as a reliable and efficient choice. Designed to perform in a wide range of operating conditions, this mechanical shaft seal is built to withstand temperatures, high pressures, and rapid speeds.
Operating Conditions:
The Heavy Duty Water Pump Mechanical Shaft Seal is engineered to excel under the following operating conditions:
Temperature: This seal can endure temperatures ranging from a chilling -40°C to a scorching 150°C.
Pressure: It can function effectively under pressures of up to 2MPa, making it suitable for applications that demand robust sealing solutions.
Speeds: With a speed capability of 13 meters per second, this seal can handle the rapid rotations often seen in industrial pumps and mixers.
Applications:
This versatile seal is suitable for various applications, including but not limited to:
Pumps: It's a fit for different types of pumps, ensuring they operate efficiently and leak-free.
Mixers: Whether in chemical processing or other industries, this seal keeps mixers performing reliably.
Rotating Equipment: Any rotating equipment dealing with oil, water, or weak corrosive solutions can benefit from this mechanical shaft seal.
Materials:
The Heavy Duty Water Pump Mechanical Shaft Seal is constructed using high-quality materials that ensure longevity and performance. The choice of materials depends on the specific operational conditions, and options include:
Rotary Ring: Available in Carbon or Silicon Carbide (SiC), providing wear resistance.
Stationary Ring: Options include Ceramic, Silicon Carbide (SiC), and Tungsten Carbide (TC), each chosen for their durability and corrosion resistance.
Secondary Seal: This seal incorporates various secondary seal materials such as NBR, EPDM, and VITON, enabling compatibility with a wide range of fluids.
Spring & Other Parts: Constructed from corrosion-resistant materials like SUS304 and SUS316 to ensure a long service life.
Choosing the right materials based on the specific operating conditions is crucial to improving the performance and lifespan of the seal.
Design Features:
Single Face, Single Spring: This design simplifies installation and maintenance, while the single spring provides reliable sealing performance.
Unbalanced Design: The unbalanced configuration ensures consistent sealing under various conditions.
Rubber Bellows Structure: The rubber bellows design is essential for preventing torsion and ensuring smooth operation.
ISO and DIN Compliance: The installation size conforms to the standards set by ISO3069 and DIN24960, ensuring compatibility and ease of integration into existing systems.
In summary, the Heavy Duty Water Pump Mechanical Shaft Seal is a high-performance solution for demanding applications with its robust materials, versatile compatibility, and thoughtful design features. Whether you're dealing with temperatures, high pressures, or rapid speeds, this seal is your dependable choice for achieving leak-free and efficient operation in a wide range of industrial equipment.
