Operating conditions:
Temperature: -40℃-125℃
Pressure: ≤0.6MPa
Speeds: ≤5m/sec
Applications: Used in the submersible pumps and sewage pumps.
Materials:
Rotary ring (Carbon/ SiC/ TC)
Stationary ring (Ceramic/ SiC/ TC)
Secondary seal (NBR/ VITON)
Spring & Other parts (SUS304/ SUS316)
Materials should be selected according to operation condition
The Double Face Rubber Bellow Water Pump Mechanical Seal is a crucial component designed to ensure the efficient and reliable performance of submersible pumps and sewage pumps. This innovative sealing solution has been meticulously crafted to excel under challenging operating conditions, making it an indispensable choice for a wide range of applications.
Operating Conditions
The Double Face Rubber Bellow Water Pump Mechanical Seal is engineered to thrive in demanding environments. Its key operating conditions include:
Temperature Range: The seal can withstand temperatures ranging from -40°C to 125°C. This impressive temperature tolerance ensures the seal remains functional even in certain conditions, guaranteeing the longevity of the equipment it's installed in.
Pressure: With a pressure rating of ≤0.6MPa, this mechanical seal effectively prevents any unwanted leaks, preserving the integrity of the pumping systems.
Speeds: Capable of handling speeds of up to ≤5m/sec, the seal offers stability and reliability, even in high-speed applications. This makes it suitable for various pump configurations.
Applications
Submersible Pumps: Submersible pumps are frequently used in applications where the pump is submerged in the fluid it is tasked with moving. These pumps are widely employed for groundwater extraction, wastewater treatment, and other similar processes. The Double Face Rubber Bellow Water Pump Mechanical Seal ensures that these pumps remain leak-free, preventing contamination and maintaining operational efficiency.
Sewage Pumps: Sewage pumps handle the challenging task of moving wastewater, sewage, and other abrasive liquids. These pumps require robust sealing solutions to prevent any leakage, and the Double Face Rubber Bellow Water Pump Mechanical Seal is ideally suited to meet this demand.
Materials
The effectiveness of the Double Face Rubber Bellow Water Pump Mechanical Seal is greatly attributed to the quality and compatibility of the materials used in its construction. The choice of materials is essential to ensure the longevity and performance of the seal, and the following materials are used in its assembly:
Rotary Ring: The rotary ring options include Carbon, Silicon Carbide (SiC), and Tungsten Carbide (TC). These materials are selected based on the specific application requirements, providing wear resistance and chemical compatibility.
Stationary Ring: The stationary ring is available in various materials, including Ceramic, Silicon Carbide (SiC), and Tungsten Carbide (TC). These options offer superb resistance to abrasion and corrosion, ensuring the seal's durability.
Secondary Seal: The secondary seal is crafted from either NBR (Nitrile Butadiene Rubber) or VITON, depending on the operating conditions and fluid compatibility. These materials are known for their sealing properties.
Spring & Other Parts: SUS304 and SUS316 stainless steel are used for springs and other components in the seal. These options offer superb resistance.
It's imperative to note that the selection of materials should be made judiciously, taking into consideration the specific operating conditions of the pump to ensure performance and a prolonged service life.
In conclusion, the Double Face Rubber Bellow Water Pump Mechanical Seal is a versatile and high-performance sealing solution designed for submersible pumps and sewage pumps.
