Operating conditions:
Temperature: -30℃-205℃
Pressure:<2.1MPa(shaft diameter≤ 75mm)
<1.3MPa(shaft diameter> 75mm)
Speeds: 25m/sec
Materials:
Rotary Ring(SIC/ Carbon/ TC)
Stationary Ring(SIC/ TC/ Ceramic)
Secondary Seal (VITON/ PTFE Coated VITON/ PTFE)
Other Parts (SUS304/ SUS316/ Titanium/ Hastelloy-C)
Materials should be selected according to operation condition
The Single Cartridge Pump Balanced Mechanical Seal is an advanced engineering solution designed to meet the demanding operating conditions in various industrial applications. This innovative mechanical seal ensures performance and reliability, making it an ideal choice for a wide range of industries, from chemical processing and petrochemicals to pharmaceuticals and wastewater treatment.
Operating Conditions:
This single cartridge pump balanced mechanical seal is engineered to excel under challenging conditions. With a broad temperature range of -30°C to 205°C, it can handle temperature fluctuations without compromising its performance. The seal operates efficiently at speeds up to 25 meters per second, making it versatile in high-speed applications. Furthermore, it is capable of sealing systems with a pressure of less than 2.1MPa for shaft diameters up to 75mm and less than 1.3MPa for shaft diameters greater than 75mm. These robust operating conditions make it suitable for a wide variety of industrial processes.
Materials:
The Single Cartridge Pump Balanced Mechanical Seal is constructed using top-quality materials, ensuring durability and longevity even in harsh environments. The choice of materials is crucial for the seal's ability to withstand the conditions it may encounter. Operators can select materials that suit their specific operational requirements:
Rotary Ring: This crucial component can be crafted from Silicon Carbide (SiC), Carbon, or Tungsten Carbide (TC). SiC is known for its good resistance, while Carbon offers self-lubrication properties. TC provides high strength and hardness.
Stationary Ring: The stationary ring can be made from Silicon Carbide (SiC), Tungsten Carbide (TC), or Ceramic. SiC offers good resistance to abrasive materials, TC provides durability, and Ceramic is known for its corrosion resistance.
Secondary Seal: The secondary seal options include VITON, PTFE Coated VITON, and PTFE. VITON is a well-regarded choice for its chemical resistance and temperature tolerance. PTFE offers outstanding non-stick and low-friction properties, ensuring a reliable seal.
Other Parts: The remaining components of the seal, such as the housing and fasteners, are available in various materials, including SUS304, SUS316, Titanium, and Hastelloy-C. These options allow for compatibility with a broad spectrum of fluids and chemicals.
Customized Selection:
The choice of materials is critical in ensuring the longevity and efficiency of the Single Cartridge Pump Balanced Mechanical Seal. To optimize performance and lifespan, it is recommended that materials be selected according to the specific operating conditions. Operators should consider the temperature range, fluid compatibility, and other environmental factors when choosing the materials for this mechanical seal.
In summary, the Single Cartridge Pump Balanced Mechanical Seal is a versatile and robust solution designed to meet the challenges of demanding industrial applications. With its wide temperature range, high-speed capabilities, and customizable material options, it provides a reliable and durable sealing solution for a wide range of industries. Selecting the appropriate materials ensures that this mechanical seal performs, even in challenging operating conditions.
